Telecom Power System
Leading Manufacturers, Exporters and Wholesaler of Digital Telecom Power System, Portable Telecom Power System, Sine Wave Telecom Power System and Single Phase Telecom Power System from Thane.
| Business Type | Manufacturer, Exporter, Supplier |
| Warranty | 1 Year |
| Country of Origin | India |
| Voltage (nominal) | 200 / 220 / 240V AC |
| Voltage (range) | 170-300VAC; De-rating <= 184VAC (Line - Neutral) |
| Frequency | 45 - 66Hz |
| Voltage (adjustable range) | -42 to -58VDC |
| Maximum Power @ Nominal Input | 3000W |
| Operating Temperature | -20 to +55 Degree C |
| Storage Temperature | -40 to +70 Degree C |
Description:
- PIPL-4860TRO Series is ideal for Small Cell High Power Mobile Tower applications with high reliability power system. It is modular, expandable and can be easily installed, also with high cost effecve & high efficiency.
- Unit is design to maintain all aspects of the power performance, less power consump!on with easy maintenance on site. Total inbuilt space area is 12U including battery Space for VRLA.
Key Features:
- Compact Design
- Easy Maintenance
- High Reliability
- Quiet Operation
- 24 / 7 Monitoring and Control
| Business Type | Manufacturer, Exporter, Supplier |
| Warranty | 1 Year |
| Country of Origin | India |
| Voltage (nominal) | 200 / 220 / 240V AC |
| Voltage (range) | 170-300VAC; De-rating <= 184VAC (Line - Neutral) |
| Voltage (adjustable range) | -42 to -58VDC |
| Maximum Power @ Nominal Input | 3000W |
| Operating Temperature | -20 to +55 Degree C |
| Storage Temperature | -40 to +70 Degree C |
| Frequency | 45 - 66Hz |
Description:
- PIPL-4860TROEM Series is ideal for Small Cell High Power Mobile Tower applications with high reliability power system. It is modular, expandable and can be easily installed, also with high cost effecve & high efficiency.
- Unit is design to maintain all aspects of the power performance, less power consump!on with easy maintenance on site. Total inbuilt space area is 12U including battery Space for VRLA.
Key Features:
- Compact Design
- Easy Maintenance
- High Reliability
- Quiet Operation
- 24 / 7 Monitoring and Control
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Capacity | 700 VA |
| Waveform | Pure Sine Wave |
| Output Frequency | 50 Hz |
| Design | Portable |
| Certification | CE |
| Degree Of Protection | IP 21 |
| Integrated Cooling | Fan |
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Phase | Single Phase |
| Input Nominal Voltage | AC 230V |
| Output Nominal Voltage | DC 48V |
| AC SPD | Class II |
| Frequency | 66Hz |
| Dimension | 600 X 550 X 750mm |
| Weight | Approx. 70Kg |
| Operating Temperature | Max +55 Degree C |
| Storage Temperature | Max 70 Degree C |
| Related Humidity | 95% Non-condensing (Max.) |
| Acoustic Noise | Less Than Or Equal To 60dBA |
| Environment | IP-55 |
| Product Code | PIPL500TR48LB |
Description:
- PIPL-500TR48LB Series is ideal for remote OLT applications withhigh reliability power system. It is modular, expandable and can be easily installed, also with high cost effecve & high efficiency.
- Unit is design to maintain all aspects of the power performance, less power consump!on with easy maintenance on site. Total inbuilt space area is 12U including LFP battery.
- Inbuilt advanced monitoring op!onal features like battery health monitoring & DC/AC system monitoring, Poten!al free contact for DC fail & Battery Low.
- Battery backup is customized as per end user need, PIPL500TR48LB provide 2 Hours backup
Key Features:
- Compact Design
- Easy Maintenance
- High Reliability
- Quiet Operation
- 24 / 7 Monitoring and Control
Applications:
- Optical Line Terminal
- 4G/5G
- Fixed Line
- Datacom
